Laboratory Small Coating Machine Compact Lab Coating Test Equipment Laboratory Scale Mini Coater

Name: Laboratory Small Coating Machine Compact Lab Coating Test Equipment Laboratory Scale Mini Coater
Brand: Lonroy
Price: 1 USD

Quality Laboratory Small Coating Machine Compact Lab Coating Test Equipment Laboratory Scale Mini Coater for sale

Brand Name : Lonroy

Place of Origin : China

MOQ : 1

Voltage : 110~220V

Frequency : 50/60Hz

Power Consumption : 48W (standby), 2000W (heating)

Protection Class : IP56

Machine Dimensions : 800 × 380 × 410 mm

Machine Weight : 44 kg

Coating Speed : 1-3 meters/minute

Coating Length : 10-450 mm

Temperature Range : Room temperature to 160℃

Coating Uniformity : ±4 microns

Coating Width : 300 × 450 mm

Coating Thickness : 0.005-5 mm (wet film)

Line Rod Dimensions : Diameter 10 × Length 400 mm

Workbench Material : Aluminum alloy + glass

Knife Material : Alloy stainless steel

Certification : ISO ASTM CE

Price : Negotaible

Packaging Details : Wooden package

Delivery Time : 5-8 work days

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Supply Ability : 200

Contact Now

Laboratory Small Coating Machine Compact Lab Coating Test Equipment Laboratory Scale Mini Coater

Product Description

Product Overview

The laboratory small coating machine uses all high-quality components and has a favorable price, and has been favored by many multinational enterprise research institutions and many well-known universities at home and abroad. It ensures the coating effect by controlling the speed and stable pressure, and guarantees the uniformity and stability of the coating. The main feature of the laboratory small coating machine is that it can be used for coating experiments on various materials such as paper, plastic, metal, PVC, PET, fabric, aluminum alloy plates, etc.

Advantage

The main advantage of the laboratory small coating machine is that it can repeatedly and continuously produce smooth, flat and flawless test samples. It is convenient for the experimenters to precisely coat on different substrates, reducing and eliminating errors caused by different coating speeds and pressures due to human factors. The coating head uses a special scraper to imitate the head of a large coating machine to ensure that the products obtained from the experiment are consistent with the quality of the production coating. The coating head can be quickly opened at 90 degrees to facilitate cleaning the scraper after each experiment.

Laboratory Small Coating Machine Compact Lab Coating Test Equipment Laboratory Scale Mini Coater

Technical Specification

Control System	Independently developed by Lonroy / PLC touch screen
Coating Method	Integrated knife/line rod (separate for individual coating)
Knife Elevator	Rear flip type (convenient for cleaning)
Coating Speed	Digitally set, 1-3 meters/minute
Length Setting	Digitally set, 10-450 mm
Temperature Control	Room temperature to 160℃ (constant temperature achievable)
Leveling Device	Equipped with leveling rods; material is flattened first before coating
Workbench Material	Aluminum alloy + glass (removable)
Clamping Tools	Automatic clamping tools
Coating Uniformity	±4 microns (depending on the material's flatness)
Width	300×450 mm
Coating Thickness	0.005-5 mm (wet film)
Machine Volume	Length 800 × Width 380 × Height 410 mm (for reference)
Machine Weight	Net weight: 44 kg (for reference)
Line Rod Device	Comes with a line rod device (line rods optional; one line rod per thickness)
Line Rod Weights	With two adjustable counterweights
Line Rod Dimensions	Diameter 10 × Length 400 mm (universal)
Knife Material	Alloy stainless steel
Power Source	Voltage: 110~220V, 50/60Hz
Power	48W (standby), 2000W (heating)
